Dräger MicroTubes Ammonia 1-100 ppm
8610130_UK
£106.31*
MicroTubes for ammonia measurement, 1 to 100 ppm range
Dräger MicroTubes for ammonia (NH₃) are short-term measurement tubes for the Dräger X-act 7000 analyser, covering 1 to 100 ppm. Even low concentrations irritate the eyes and airways, and leaks from refrigeration circuits are common.
- Measuring range 1 to 100 ppm – matched to the concentrations that matter when you assess ammonia exposure or trace a leak.
- Read out automatically by the X-act 7000 – the analyser evaluates the tube and shows the concentration directly, so there is no colour scale to judge by eye and no operator interpretation to defend afterwards.
- Ready to use straight from the box – no calibration, no warm-up time and no sensor to replace; each tube carries its own batch data for the instrument to read.
- A documented spot measurement in minutes – ideal where a permanently installed monitor would be disproportionate but a defensible reading is still needed.
Measured gas and detection range
- Ammonia (NH₃)
Technical data of these MicroTubes
- Measuring range: 1 to 100 ppm
- Measurement time: approx. 10 to 75 s
- Standard deviation: ± 25 %
- Permissible ambient temperature: 0 to 40 °C
- Permissible humidity: 1 to 30 mg/L
Typical applications for these MicroTubes
- Refrigeration plant, waste-water treatment, agriculture and fertiliser production.
Instrument compatible with these MicroTubes
- Dräger X-act 7000
