Pac 8000 Single Gas Monitor for Ammonia (NH3) US

SRM12815

Rental fee per Day

$8.02*

excluding tax and shipping costs

Available

Transit Zone

Select rental period:

Please note: if you need the device quicker, there is an option to choose Express Delivery in the checkout. If you should require a specific device configuration, you can also leave a comment during checkout.

The Pac 8000 NH3 gas warning device reliably and precisely detects the concentration of ammonia and warns of dangerous gas concentration.

Single gas measurement device for personal measurement
XXS sensor technology with high reaction speed and membrane filter
Standard measurement range: 0 - 300 ppm, A1/A2 alarm thresholds: 20/40 ppm
360° alarm signal, acoustic (90 dB) and optical
The gas detector features a robust, ergonomic housing for use under extreme conditions
Large and user-friendly display with bright backlight
Storage of concentrations and events with date and time

Conduct the required function tests before each use with Dräger test and calibration stations and the associated test gases. The basis for the function tests are the information sheets T021 / T023 (DGUV Information 213-056 or DGUV Information 213-057). Further information can be found here.

If you desire a custom alarm threshold configuration, please specify the alarm thresholds in the comment field at the end of the ordering process.

For more information about the product, visit our website. Please follow the link.

Technical Data - Dräger Sensor XXS NH3

Detection Limit	4 ppm
Resolution	1 ppm
Measurement Range	0 - 300 ppm NH3 (Ammonia)
Response Time	≤ 10 seconds (t50)
Precision Sensitivity	≤ ± 3% of measured value
Long-term Drift (at 20 °C)	Zero Point: ≤ ± 5 ppm/year Sensitivity: ≤ ± 2% of measured value/month
Start-up Time	≤ 12 hours
Environmental Conditions	Temperature: (-40 to 50) °C (-40 to 122) °F Humidity: (10 to 90)% RH Pressure: (700 to 1300) hPa
Temperature Influence	Zero Point: ≤ ± 5 ppm Sensitivity: ≤ ± 5% of measured value
Humidity Influence	Zero Point: ≤ ± 0.1 ppm/% RH Sensitivity: ≤ ± 0.2% of measured value/% RH
Test Gas	approx. 10 to 75 ppm NH3

Relevant Cross Sensitivities - Dräger Sensor XXS NH3

The values indicated in the table are guideline values and apply to new sensors. The specified values may vary by ±30%. The sensor may also be sensitive to other gases (data available on request from Dräger). Gas mixtures may be displayed as a total. Gases with negative sensitivity can negate a positive NH3 display. It should be checked if gas mixtures are present.

Gas/Vapor	Concentration	Display in ppm NH3
Chlorine (Cl2)	10 ppm	≤ 30 (–)
Hydrochloric Acid (HCl)	20 ppm	≤ 15 (–)
Diethanolamine (C4H11NO2)	10 ppm	5 ppm
Ethanol (C2H5OH)	250 ppm	≤ 40
Ethine (C2H2)	100 ppm	no influence
Ethyldimethylamine (C4H11N)	50 ppm	30 ppm
Carbon Dioxide (CO2)	10 vol.-%	no influence
Carbon Monoxide (CO)	1000 ppm	no influence
Phosphine (PH3)	1 ppm	≤ 2
Hydrogen Sulfide (H2S)	20 ppm	≤ 70
Nitrogen Dioxide (NO2)	20 ppm	≤ 10 (–)
Nitric Oxide (NO)	20 ppm	≤ 10
Hydrogen (H2)	1000 ppm	≤ 4

(-) negative sign of deviation

Rental Advanced:	Yes
Rental item or Consumable?:	Rental items
Sensors:	NH3
